• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Keyseat	5/8 x 5/16
Outside Diameter (in)	5.375 in
Material	Sintered Steel or Ductile Iron
Bore Size (in)	2.6875 in
Model Name	R1-R2_Type1_BushingMaster
Length Through Bore (in)	4.875 in
Cap Screws (Size)	3/8 x 1 3/4
Bushing Type	R2
Compatible Bore Size [Max] (in)	2.6875 in
Wrench Torque (in-lb)	348
Total Length (in)	4.875 in
Product Type	Split Taper Bushing
Bore Type	Inch
Cap Screws (No.)	3

General Specifications

UPC	662289181025
Weight	9.63 LB
Packaged Length	6.00 IN
Packaged Width	6.00 IN
Packaged Height	5.10 IN
