• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Model Name	R1-R2_Type2_BushingMaster
Total Length (in)	2.875 in
Bushing Type	R1
Wrench Torque (in-lb)	348
Length Through Bore (in)	2.875 in
Bore Size (in)	3.125 in
Compatible Bore Size [Max] (in)	3.125 in
Cap Screws (Size)	3/8 x 1 3/4
Keyseat	3/4 x 3/8
Product Type	Split Taper Bushing
Material	Sintered Steel or Ductile Iron
Outside Diameter (in)	5.375 in
Bore Type	Inch
Cap Screws (No.)	3

General Specifications

UPC	662289260706
Weight	5.53 LB
Packaged Length	5.50 IN
Packaged Width	5.70 IN
Packaged Height	3.20 IN
