• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Cap Screws (Size)	3/8 x 1 3/4
Keyseat	5/8 x 5/16
Model Name	R1-R2_Type1_BushingMaster
Total Length (in)	2.875 in
Length Through Bore (in)	2.875 in
Wrench Torque (in-lb)	348
Material	Sintered Steel or Ductile Iron
Bushing Type	R1
Product Type	Split Taper Bushing
Bore Size (in)	2.625 in
Compatible Bore Size [Max] (in)	2.625 in
Outside Diameter (in)	5.375 in
Bore Type	Inch
Cap Screws (No.)	3
Flange Type	Solid Flange
Includes	Set Screw, Cap Screws and Ext. Key
Screw Length	1.75
Flange Thickness	0.625
Barrel Diameter (Small End)	3.875
Barrel Diameter (Large End)	4
Thread Size	3/8-16
Mounting Type	Conventional
Bolt Circle Diameter (in)	4.625

General Specifications

UPC	662289140688
Weight	6.73 LB
Packaged Length	5.50 IN
Packaged Width	5.60 IN
Packaged Height	3.10 IN
