• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Material	Sintered Steel or Ductile Iron
Outside Diameter (in)	5.375 in
Bore Size (in)	2.6875 in
Cap Screws (Size)	3/8 x 1 3/4
Total Length (in)	2.875 in
Bushing Type	R1
Compatible Bore Size [Max] (in)	2.6875 in
Keyseat	5/8 x 5/16
Model Name	R1-R2_Type1_BushingMaster
Product Type	Split Taper Bushing
Length Through Bore (in)	2.875 in
Wrench Torque (in-lb)	348
Cap Screws (No.)	3
Bore Type	Inch

General Specifications

UPC	662289270637
Weight	6.53 LB
Packaged Length	5.50 IN
Packaged Width	5.60 IN
Packaged Height	3.10 IN
