• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Length Through Bore (in)	2.875 in
Outside Diameter (in)	5.375 in
Wrench Torque (in-lb)	348
Total Length (in)	2.875 in
Material	Sintered Steel or Ductile Iron
Bushing Type	R1
Bore Size (in)	1.1875 in
Keyseat	1/4 x 1/8
Product Type	Split Taper Bushing
Cap Screws (Size)	3/8 x 1 3/4
Compatible Bore Size [Max] (in)	1.1875 in
Model Name	R1-R2_Type1_BushingMaster
Bore Type	Inch
Cap Screws (No.)	3

General Specifications

UPC	662289230471
Weight	9.90 LB
Packaged Length	5.50 IN
Packaged Width	5.70 IN
Packaged Height	3.20 IN
HTC	8483.90.8080
Country of Origin	Mexico
