• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Length Through Bore (in)	5 in
Product Type	Split Taper Bushing
Bushing Type	Q3
Cap Screws (Size)	3/8 x 1 1/4
Model Name	Q3-Type2_Bushing_Master
Compatible Bore Size [Max] (in)	2.1875 in
Bore Size (in)	2.1875 in
Total Length (in)	5 in
Keyseat	1/2 x 1/4
Wrench Torque (in-lb)	348
Material	Sintered Steel or Ductile Iron
Outside Diameter (in)	4.125 in
Cap Screws (No.)	3
Bore Type	Inch

General Specifications

UPC	662289110353
Weight	4.30 LB
Packaged Length	4.13 IN
Packaged Width	4.13 IN
Packaged Height	5.00 IN
HTC	8483.90.8080
Country of Origin	Mexico
