• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (in)	2.5 in
Material	Sintered Steel or Ductile Iron
Compatible Bore Size [Max] (in)	2.5 in
Wrench Torque (in-lb)	348
Model Name	Q2-Type2_Bushing_Master
Keyseat	5/8 x 5/16
Cap Screws (Size)	3/8 x 1 1/4
Total Length (in)	3.5 in
Length Through Bore (in)	3.5 in
Outside Diameter (in)	4.125 in
Bushing Type	Q2
Product Type	Split Taper Bushing
Cap Screws (No.)	3
Bore Type	Inch

General Specifications

UPC	662289250196
Weight	2.47 LB
Packaged Length	4.30 IN
Packaged Width	4.50 IN
Packaged Height	3.60 IN
