• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Total Length (in)	2.5 in
Keyseat (mm)	10 x 4 mm
Model Name	Q1-Type1_Bushing_Master
Material	Sintered Steel or Ductile Iron
Bushing Type	Q1
Outside Diameter (in)	4.125 in
Cap Screws (Size)	3/8 x 1 1/4
Bore Size (mm)	36 mm
Wrench Torque (in-lb)	348
Outside Diameter (mm)	104.775 mm
Product Type	Split Taper Bushing
Total Length (mm)	63.5 mm
Compatible Bore Size [Max] (mm)	36 mm
Length Through Bore (mm)	63.5 mm
Bore Type	Metric
Cap Screws (No.)	3
Bolt Circle Diameter (in)	3.375
Barrel Diameter (Large End)	2.875
Mounting Type	Conventional
Flange Type	Solid Flange
Screw Length	1.25
Flange Thickness	0.5
Includes	Cap Screws and Ext. Key
Barrel Diameter (Small End)	2.7657
Thread Size	3/8-16

General Specifications

UPC	662289173341
Weight	3.90 LB
Packaged Length	4.19 IN
Packaged Width	4.19 IN
Packaged Height	2.50 IN
HTC	8483.90.8080
Country of Origin	Mexico
