• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Model Name	Q1-Type2_Bushing_Master
Outside Diameter (in)	4.125 in
Product Type	Split Taper Bushing
Keyseat	5/8 x 5/16
Cap Screws (Size)	3/8 x 1 1/4
Bore Size (in)	2.625 in
Wrench Torque (in-lb)	348
Compatible Bore Size [Max] (in)	2.625 in
Material	Sintered Steel or Ductile Iron
Total Length (in)	2.5 in
Length Through Bore (in)	2.5 in
Bushing Type	Q1
Cap Screws (No.)	3
Bore Type	Inch
Bolt Circle Diameter (in)	3.375
Mounting Type	Conventional
Thread Size	3/8-16
Flange Thickness	0.5
Screw Length	1.25
Flange Type	Solid Flange
Includes	Cap Screws & Spcl Key
Barrel Diameter (Large End)	2.875
Barrel Diameter (Small End)	2.7657

General Specifications

UPC	662289199914
Weight	1.79 LB
Packaged Length	4.30 IN
Packaged Width	4.50 IN
Packaged Height	2.70 IN
