• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Length Through Bore (in)	2.5 in
Bushing Type	Q1
Outside Diameter (in)	4.125 in
Bore Size (in)	2.5 in
Product Type	Split Taper Bushing
Compatible Bore Size [Max] (in)	2.5 in
Total Length (in)	2.5 in
Model Name	Q1-Type2_Bushing_Master
Keyseat	5/8 x 5/16
Wrench Torque (in-lb)	348
Cap Screws (Size)	3/8 x 1 1/4
Material	Sintered Steel or Ductile Iron
Cap Screws (No.)	3
Bore Type	Inch

General Specifications

UPC	662289139866
Weight	2.02 LB
Packaged Length	4.30 IN
Packaged Width	4.40 IN
Packaged Height	2.60 IN
