• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (mm)	20 mm
Compatible Bore Size [Max] (mm)	20 mm
Keyseat (mm)	6 x 3 mm
Model Name	P1_Bushing-Type1_Master
Outside Diameter (in)	3 in
Product Type	Split Taper Bushing
Material	Sintered Steel or Ductile Iron
Cap Screws (Size)	5/16 x 1
Wrench Torque (in-lb)	192
Outside Diameter (mm)	76.2 mm
Bushing Type	P1
Total Length (mm)	49.2125 mm
Length Through Bore (mm)	49.2125 mm
Total Length (in)	1.9375 in
Cap Screws (No.)	3
Bore Type	Metric
Thread Size	5/16-18
Flange Thickness	0.375
Barrel Diameter (Small End)	1.8555
Barrel Diameter (Large End)	1.9375
Bolt Circle Diameter (in)	2.4375
Screw Length	1
Flange Type	Solid Flange
Mounting Type	Conventional
Includes	Cap Screws and Ext. Key

General Specifications

UPC	662289331673
Weight	1.63 LB
Packaged Length	3.20 IN
Packaged Width	3.20 IN
Packaged Height	2.00 IN
HTC	8483.90.8080
Country of Origin	Mexico
