• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Model Name	P1_Bushing-Type1_Master
Bore Size (in)	1.125 in
Length Through Bore (in)	1.9375 in
Keyseat	1/4 x 1/8
Cap Screws (Size)	5/16 x 1
Compatible Bore Size [Max] (in)	1.125 in
Wrench Torque (in-lb)	192
Total Length (in)	1.9375 in
Bushing Type	P1
Outside Diameter (in)	3 in
Product Type	Split Taper Bushing
Material	Sintered Steel or Ductile Iron
Cap Screws (No.)	3
Bore Type	Inch
Mounting Type	Conventional
Barrel Diameter (Large End)	1.9375
Thread Size	5/16-18
Includes	Cap Screws and Ext. Key
Screw Length	1
Flange Thickness	0.375
Bolt Circle Diameter (in)	2.4375
Flange Type	Solid Flange
Barrel Diameter (Small End)	1.8555

General Specifications

UPC	662289139255
Weight	1.38 LB
Packaged Length	3.20 IN
Packaged Width	3.20 IN
Packaged Height	2.00 IN
