• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Type	Inch
Total Length (in)	0.89 in
Mounting Type	Conventional
Model Name	QD-JA_Bushing_Master
Keyway	3/16 x 3/32
Compatible Bore Size [Max] (in)	0.875 in
Product Type	Q-D Bushing
Torque Capacity (in-lb)	1,000
Cap Screws (Bolt Circle)	1.65625
Length Through Bore (in)	0.89 in
Cap Screws (No.)	3
Wrench Torque (ft.-lbs.)	6
Cap Screws (Size)	10-24 x 1
Bushing Type	JA
Outside Diameter (in)	2 in
Bore Size (in)	0.875 in
Barrel Diameter	1.375 in
Flange Thickness	0.33 in
Barrel Length	0.56 in
Material	Steel

General Specifications

UPC	662289354467
Weight	0.33 LB
Packaged Length	3.40 IN
Packaged Width	3.10 IN
Packaged Height	1.50 IN
