• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Product Type	Q-D Bushing
Bushing Type	JA
Model Name	QD-JA_Bushing_Master
Outside Diameter (in)	2 in
Length Through Bore (in)	0.89 in
Cap Screws (Bolt Circle)	1.65625
Mounting Type	Conventional
Compatible Bore Size [Max] (in)	0.9375 in
Cap Screws (Size)	10-24 x 1
Total Length (in)	0.89 in
Cap Screws (No.)	3
Wrench Torque (ft.-lbs.)	6
Bore Type	Inch
Torque Capacity (in-lb)	1,000
Keyway	1/4 x 1/8
Bore Size (in)	0.9375 in
Barrel Length	0.56 in
Flange Thickness	0.33 in
Barrel Diameter	1.375 in
Material	Steel

General Specifications

UPC	662289384495
Weight	0.40 LB
Packaged Length	3.06 IN
Packaged Width	3.06 IN
Packaged Height	1.31 IN
HTC	8483.90.8080
Country of Origin	Mexico
