• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Model Name	QD-JA_Bushing_Master
Bore Type	Inch
Mounting Type	Conventional
Length Through Bore (in)	0.89 in
Cap Screws (No.)	3
Wrench Torque (ft.-lbs.)	6
Torque Capacity (in-lb)	1,000
Cap Screws (Bolt Circle)	1.65625
Bushing Type	JA
Compatible Bore Size [Max] (in)	0.6875 in
Keyway	3/16 x 3/32
Product Type	Q-D Bushing
Outside Diameter (in)	2 in
Total Length (in)	0.89 in
Cap Screws (Size)	10-24 x 1
Bore Size (in)	0.6875 in
Flange Thickness	0.33 in
Material	Steel
Barrel Length	0.56 in
Barrel Diameter	1.375 in

General Specifications

UPC	662289344451
Weight	0.44 LB
Packaged Length	3.20 IN
Packaged Width	3.30 IN
Packaged Height	1.40 IN
HTC	8483.90.8080
Country of Origin	Mexico
