• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Length Through Bore (in)	0.89 in
Model Name	QD-JA_Bushing_Master
Total Length (in)	0.89 in
Bore Type	Inch
Mounting Type	Conventional
Keyway	1/4 x 1/8
Cap Screws (Size)	10-24 x 1
Outside Diameter (in)	2 in
Bushing Type	JA
Cap Screws (No.)	3
Wrench Torque (ft.-lbs.)	6
Product Type	Q-D Bushing
Cap Screws (Bolt Circle)	1.65625
Torque Capacity (in-lb)	1,000
Compatible Bore Size [Max] (in)	1.0625 in
Bore Size (in)	1.0625 in
Barrel Length	0.56 in
Material	Steel
Barrel Diameter	1.375 in
Flange Thickness	0.33 in

General Specifications

UPC	662289364541
Weight	0.35 LB
Packaged Length	3.20 IN
Packaged Width	3.30 IN
Packaged Height	1.40 IN
HTC	8483.90.8080
Country of Origin	Mexico
