• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.
• Clear Pack packaging for end cap display

Technical Specifications

Product Type	Split Taper Bushing
Wrench Torque (in-lb)	95
Length Through Bore (in)	1.25 in
Compatible Bore Size [Max] (in)	0.625 in
Total Length (in)	1.25 in
Bushing Type	H
Cap Screws (Size)	1/4 x 3/4
Material	Sintered Steel or Ductile Iron
Outside Diameter (in)	2.5 in
Bore Size (in)	0.625 in
Keyseat	3/16 x 3/32
Model Name	H-Bushing_1_Master
Bore Type	Inch
Cap Screws (No.)	2

General Specifications

UPC	662460590769
Weight	0.72 LB
Packaged Length	5.60 IN
Packaged Width	7.25 IN
Packaged Height	1.75 IN
HTC	8483.90.8080
Country of Origin	United States of America
