• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Outside Diameter (in)	2.5 in
Model Name	H-Bushing_1_Master
Compatible Bore Size [Max] (in)	0.96875 in
Keyseat	1/4 x 1/8
Product Type	Split Taper Bushing
Total Length (in)	1.25 in
Bore Size (in)	0.96875 in
Wrench Torque (in-lb)	95
Bushing Type	H
Cap Screws (Size)	1/4 x 3/4
Material	Sintered Steel or Ductile Iron
Length Through Bore (in)	1.25 in
Cap Screws (No.)	2
Bore Type	Inch

General Specifications

UPC	662289320110
Weight	0.65 LB
Packaged Length	2.80 IN
Packaged Width	2.60 IN
Packaged Height	1.40 IN
HTC	8483.90.8080
Country of Origin	Mexico
