• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Total Length (in)	1.25 in
Material	Sintered Steel or Ductile Iron
Bushing Type	H
Outside Diameter (in)	2.5 in
Model Name	H-Bushing_1_Master
Wrench Torque (in-lb)	95
Length Through Bore (mm)	31.75 mm
Keyseat (mm)	8 x 3.5 mm
Cap Screws (Size)	1/4 x 3/4
Bore Size (mm)	30 mm
Product Type	Split Taper Bushing
Compatible Bore Size [Max] (mm)	30 mm
Outside Diameter (mm)	63.5 mm
Total Length (mm)	31.75 mm
Cap Screws (No.)	2
Bore Type	Metric

General Specifications

UPC	662289233151
Weight	0.52 LB
Packaged Length	2.70 IN
Packaged Width	2.80 IN
Packaged Height	1.50 IN
