• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (in)	0.75 in
Total Length (in)	1.25 in
Compatible Bore Size [Max] (in)	0.75 in
Cap Screws (Size)	1/4 x 3/4
Bushing Type	H
Outside Diameter (in)	2.5 in
Model Name	H-Bushing_1_Master
Wrench Torque (in-lb)	95
Material	Sintered Steel or Ductile Iron
Keyseat	3/16 x 3/32
Product Type	Split Taper Bushing
Length Through Bore (in)	1.25 in
Cap Screws (No.)	2
Bore Type	Inch

General Specifications

UPC	662289109012
Weight	0.70 LB
Packaged Length	2.60 IN
Packaged Width	2.70 IN
Packaged Height	1.40 IN
HTC	8483.90.8080
Country of Origin	United States of America
