• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (in)	1.1875 in
Keyseat	1/4 x 1/8
Wrench Torque (in-lb)	95
Total Length (in)	1.25 in
Outside Diameter (in)	2.5 in
Bushing Type	H
Cap Screws (Size)	1/4 x 3/4
Length Through Bore (in)	1.25 in
Compatible Bore Size [Max] (in)	1.1875 in
Product Type	Split Taper Bushing
Material	Sintered Steel or Ductile Iron
Model Name	H-Bushing_1_Master
Bore Type	Inch
Cap Screws (No.)	2
Barrel Diameter (Large End)	1.625
Screw Length	0.75
Bolt Circle Diameter (in)	2
Barrel Diameter (Small End)	1.57
Mounting Type	Conventional
Flange Type	Solid Flange
Thread Size	1/4-20
Flange Thickness	0.25
Includes	Cap Screws

General Specifications

UPC	662289309030
Weight	0.51 LB
Packaged Length	2.50 IN
Packaged Width	2.70 IN
Packaged Height	1.50 IN
HTC	8483.90.8080
Country of Origin	United States of America
