• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Model Name	G_Bushing_Master
Compatible Bore Size [Max] (in)	0.6875 in
Cap Screws (Size)	1/4 x 5/8
Bushing Type	G
Wrench Torque (in-lb)	95
Material	Sintered Steel or Ductile Iron
Total Length (in)	1 in
Product Type	Split Taper Bushing
Outside Diameter (in)	2 in
Keyseat	3/16 x 3/32
Bore Size (in)	0.6875 in
Length Through Bore (in)	1 in
Bore Type	Inch
Cap Screws (No.)	2

General Specifications

UPC	662289118861
Weight	0.36 LB
Packaged Length	2.56 IN
Packaged Width	2.56 IN
Packaged Height	1.38 IN
HTC	8483.90.8080
Country of Origin	Mexico
