• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Torque Capacity (in-lb)	30,000
Cap Screws (Bolt Circle)	5.625
Bore Type	Inch
Total Length (in)	3.68 in
Model Name	QD-F_Bushing_Master
Bushing Type	F
Mounting Type	Conventional
Length Through Bore (in)	3.68 in
Compatible Bore Size [Max] (in)	2.4375 in
Keyway	5/8 x 5/16
Cap Screws (Size)	9/16-12 x 3 5/8
Outside Diameter (in)	6.625 in
Product Type	Q-D Bushing
Cap Screws (No.)	3
Wrench Torque (ft.-lbs.)	75
Bore Size (in)	2.4375 in
Barrel Length	2.7425 in
Barrel Diameter	4.375 in
Flange Thickness	0.9375 in
Material	Gray Iron - G3029

General Specifications

UPC	662289350155
Weight	14.96 LB
Packaged Length	7.70 IN
Packaged Width	7.70 IN
Packaged Height	4.10 IN
