• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Compatible Bore Size [Max] (in)	2.625 in
Model Name	QD-F_Bushing_Master
Outside Diameter (in)	6.625 in
Keyway	5/8 x 5/16
Length Through Bore (in)	3.68 in
Cap Screws (Size)	9/16-12 x 3 5/8
Total Length (in)	3.68 in
Cap Screws (Bolt Circle)	5.625
Mounting Type	Conventional
Bushing Type	F
Cap Screws (No.)	3
Wrench Torque (ft.-lbs.)	75
Product Type	Q-D Bushing
Bore Type	Inch
Torque Capacity (in-lb)	30,000
Bore Size (in)	2.625 in
Material	Gray Iron - G3028
Flange Thickness	0.9375 in
Barrel Diameter	4.375 in
Barrel Length	2.7425 in

General Specifications

UPC	662289360161
Weight	14.20 LB
Packaged Length	7.70 IN
Packaged Width	7.70 IN
Packaged Height	4.20 IN
HTC	8483.90.8080
Country of Origin	Mexico
