• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Outside Diameter (in)	6.625 in
Cap Screws (Bolt Circle)	5.625
Length Through Bore (in)	3.68 in
Compatible Bore Size [Max] (in)	2.5 in
Total Length (in)	3.68 in
Torque Capacity (in-lb)	30,000
Product Type	Q-D Bushing
Cap Screws (Size)	9/16-12 x 3 5/8
Cap Screws (No.)	3
Keyway	5/8 x 5/16
Bushing Type	F
Mounting Type	Conventional
Model Name	QD-F_Bushing_Master
Wrench Torque (ft.-lbs.)	75
Bore Type	Inch
Bore Size (in)	2.5 in
Material	Gray Iron - G3018
Barrel Length	2.7425 in
Barrel Diameter	4.375 in
Flange Thickness	0.9375 in

General Specifications

UPC	662289380183
Weight	14.73 LB
Packaged Length	7.70 IN
Packaged Width	7.70 IN
Packaged Height	4.10 IN
