• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Mounting Type	Conventional
Cap Screws (No.)	3
Model Name	QD-F_Bushing_Master
Cap Screws (Size)	9/16-12 x 3 5/8
Length Through Bore (in)	3.68 in
Cap Screws (Bolt Circle)	5.625
Torque Capacity (in-lb)	30,000
Wrench Torque (ft.-lbs.)	75
Outside Diameter (in)	6.625 in
Keyway	1/2 x 1/4
Total Length (in)	3.68 in
Bore Type	Inch
Product Type	Q-D Bushing
Compatible Bore Size [Max] (in)	1.875 in
Bushing Type	F
Bore Size (in)	1.875 in
Material	Gray Iron - G3014
Barrel Diameter	4.375 in
Flange Thickness	0.9375 in
Barrel Length	2.7425 in

General Specifications

UPC	662289350087
Weight	16.71 LB
Packaged Length	7.70 IN
Packaged Width	7.70 IN
Packaged Height	4.10 IN
HTC	8483.90.8080
Country of Origin	Mexico
