• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Type	Metric
Torque Capacity (in-lb)	20,000
Product Type	Q-D Bushing
Total Length (in)	2.64 in
Compatible Bore Size [Max] (mm)	65 mm
Keyway	18mm x 5.5mm
Cap Screws (Size)	1/2-13 x 2 3/4
Total Length (mm)	67.056 mm
Wrench Torque (ft.-lbs.)	60
Outside Diameter (in)	6 in
Bushing Type	E
Cap Screws (No.)	3
Length Through Bore (mm)	67.056 mm
Cap Screws (Bolt Circle)	5
Mounting Type	Conventional
Outside Diameter (mm)	152.4 mm
Bore Size (mm)	65 mm
Barrel Length	1.89 in
Material	Ductile Iron-Grade 65-45-62
Flange Thickness	0.75 in
Barrel Diameter	3.834 in

General Specifications

UPC	662289615391
Weight	7.76 LB
Packaged Length	6.40 IN
Packaged Width	6.60 IN
Packaged Height	3.30 IN
HTC	8483.90.8080
Country of Origin	Mexico
