• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Length Through Bore (mm)	67.056 mm
Outside Diameter (in)	6 in
Cap Screws (Bolt Circle)	5
Total Length (in)	2.64 in
Wrench Torque (ft.-lbs.)	60
Keyway	10mm x 4mm
Total Length (mm)	67.056 mm
Cap Screws (No.)	3
Outside Diameter (mm)	152.4 mm
Bushing Type	E
Bore Type	Metric
Mounting Type	Conventional
Compatible Bore Size [Max] (mm)	40 mm
Torque Capacity (in-lb)	20,000
Cap Screws (Size)	1/2-13 x 2 3/4
Product Type	Q-D Bushing
Bore Size (mm)	40 mm
Barrel Diameter	3.834 in
Material	Ductile Iron-Grade 65-45-56
Barrel Length	1.89 in
Flange Thickness	0.75 in

General Specifications

UPC	662289615285
Weight	9.85 LB
Packaged Length	6.40 IN
Packaged Width	6.60 IN
Packaged Height	3.30 IN
HTC	8483.90.8080
Country of Origin	Mexico
