• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Type	Inch
Compatible Bore Size [Max] (in)	2 in
Wrench Torque (ft.-lbs.)	60
Torque Capacity (in-lb)	20,000
Outside Diameter (in)	6 in
Model Name	QD-E_Bushing_Master
Bushing Type	E
Keyway	1/2 x 1/4
Cap Screws (Size)	1/2-13 x 2 3/4
Product Type	Q-D Bushing
Total Length (in)	2.64 in
Cap Screws (No.)	3
Length Through Bore (in)	2.64 in
Mounting Type	Conventional
Cap Screws (Bolt Circle)	5
Bore Size (in)	2 in
Material	Ductile Iron-Grade 65-45-29
Barrel Diameter	3.834 in
Flange Thickness	0.75 in
Barrel Length	1.89 in

General Specifications

UPC	662289354245
Weight	9.13 LB
Packaged Length	6.40 IN
Packaged Width	6.60 IN
Packaged Height	3.30 IN
