• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Cap Screws (Size)	1/2-13 x 2 3/4
Length Through Bore (in)	2.64 in
Total Length (in)	2.64 in
Compatible Bore Size [Max] (in)	2.5 in
Outside Diameter (in)	6 in
Wrench Torque (ft.-lbs.)	60
Cap Screws (Bolt Circle)	5
Product Type	Q-D Bushing
Cap Screws (No.)	3
Keyway	5/8 x 5/16
Bushing Type	E
Torque Capacity (in-lb)	20,000
Mounting Type	Conventional
Bore Type	Inch
Model Name	QD-E_Bushing_Master
Bore Size (in)	2.5 in
Barrel Length	1.89 in
Flange Thickness	0.75 in
Barrel Diameter	3.834 in
Material	Ductile Iron-Grade 65-45-31

General Specifications

UPC	662289321179
Weight	7.83 LB
Packaged Length	6.40 IN
Packaged Width	6.60 IN
Packaged Height	3.50 IN
