• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Torque Capacity (in-lb)	20,000
Bushing Type	E
Total Length (in)	2.64 in
Outside Diameter (in)	6 in
Length Through Bore (in)	2.64 in
Compatible Bore Size [Max] (in)	1.625 in
Bore Type	Inch
Cap Screws (Size)	1/2-13 x 2 3/4
Mounting Type	Conventional
Keyway	3/8 x 3/16
Wrench Torque (ft.-lbs.)	60
Model Name	QD-E_Bushing_Master
Cap Screws (Bolt Circle)	5
Cap Screws (No.)	3
Product Type	Q-D Bushing
Bore Size (in)	1.625 in
Material	Ductile Iron-Grade 65-45-24
Barrel Length	1.89 in
Barrel Diameter	3.834 in
Flange Thickness	0.75 in

General Specifications

UPC	662289364152
Weight	9.85 LB
Packaged Length	6.40 IN
Packaged Width	6.60 IN
Packaged Height	3.40 IN
HTC	8483.90.8080
Country of Origin	Mexico
