• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Compatible Bore Size [Max] (in)	1.1875 in
Cap Screws (Bolt Circle)	5
Total Length (in)	2.64 in
Wrench Torque (ft.-lbs.)	60
Model Name	QD-E_Bushing_Master
Mounting Type	Conventional
Cap Screws (No.)	3
Torque Capacity (in-lb)	20,000
Cap Screws (Size)	1/2-13 x 2 3/4
Bushing Type	E
Product Type	Q-D Bushing
Bore Type	Inch
Keyway	1/4 x 1/8
Length Through Bore (in)	2.64 in
Outside Diameter (in)	6 in
Bore Size (in)	1.1875 in
Material	Ductile Iron-Grade 65-45-20
Barrel Diameter	3.834 in
Flange Thickness	0.75 in
Barrel Length	1.89 in

General Specifications

UPC	662289394036
Weight	10.50 LB
Packaged Length	6.30 IN
Packaged Width	6.30 IN
Packaged Height	3.40 IN
HTC	8483.90.8080
Country of Origin	Mexico
