• EPDM Material provides expanded operating temperature range to -60F degrees to 250F degrees which helps ensure long-life and reliable performance in the moste demanding climates and heat sensitive applications.
• Precision Molded Cogs - Provide more surface area for heat dissipation and increase belt flexibility. Cooler running means longer life. Browning Notched belts assure longer life when replacing existing Wrapped V-Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.
• Raw-Edge Sidewalls - Improved gripping contract with pulley sidewalls. Assures less vibration and Smoother , quieter performance. Notched belts provide higher horsepower than wrapped belts.

Technical Specifications

Belt Section	BX
Pitch Length	255.3
Type	Gripnotch Notched V-Belts
Material	EPDM
Outside Length/Diameter (in)	256.5 in
Product Type	Notched Belt
Operating Temperature [Max] ºF	250 °F
Operating Temperature [Max] ºC	121 °C
Outside Diameter (in)	256.5 in
Efficiency (%)	0.98
Width (in)	0.6563 in
Number of Ribs	1
Reinforcing cord material	Nylon
Height	0.4375
Section Size	BX
Construction Type	Cogged
Belt Series	Gripnotch

General Specifications

UPC	662289359776
Weight	2.55 LB
Packaged Length	14.15 IN
Packaged Width	14.30 IN
Packaged Height	2.85 IN
HTC	4010.39.1000
Country of Origin	United States of America
