• EPDM Material provides expanded operating temperature range to -60F degrees to 250F degrees which helps ensure long-life and reliable performance in the moste demanding climates and heat sensitive applications.
• Precision Molded Cogs - Provide more surface area for heat dissipation and increase belt flexibility. Cooler running means longer life. Browning Notched belts assure longer life when replacing existing Wrapped V-Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.
• Raw-Edge Sidewalls - Improved gripping contract with pulley sidewalls. Assures less vibration and Smoother , quieter performance. Notched belts provide higher horsepower than wrapped belts.

Technical Specifications

Type	Gripnotch Notched V-Belts
Belt Section	BX
Pitch Length	174.8
Material	EPDM
Operating Temperature [Max] ºC	121 °C
Operating Temperature [Max] ºF	250 °F
Product Type	Notched Belt
Efficiency (%)	0.98
Outside Diameter (in)	176 in
Outside Length/Diameter (in)	176 in
Width (in)	0.6563 in
Height	0.4375
Number of Ribs	1
Reinforcing cord material	Nylon
Band Type	Belt with Ends Joined
Construction Type	Cogged
Belt Series	Gripnotch
Section Size	BX

General Specifications

UPC	662289155408
Weight	1.49 LB
Packaged Length	12.40 IN
Packaged Width	13.15 IN
Packaged Height	2.15 IN
HTC	4010.39.1000
Country of Origin	United States of America
