• EPDM Material provides expanded operating temperature range to -60F degrees to 250F degrees which helps ensure long-life and reliable performance in the moste demanding climates and heat sensitive applications.
• Precision Molded Cogs - Provide more surface area for heat dissipation and increase belt flexibility. Cooler running means longer life. Browning Notched belts assure longer life when replacing existing Wrapped V-Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.
• Raw-Edge Sidewalls - Improved gripping contract with pulley sidewalls. Assures less vibration and Smoother , quieter performance. Notched belts provide higher horsepower than wrapped belts.

Technical Specifications

Type	Gripnotch Notched V-Belts
Pitch Length	149.8
Belt Section	BX
Material	EPDM
Operating Temperature [Max] ºF	250 °F
Outside Diameter (in)	151 in
Operating Temperature [Max] ºC	121 °C
Outside Length/Diameter (in)	151 in
Efficiency (%)	0.98
Product Type	Notched Belt
Width (in)	0.656 in
Belt Series	Classical Series - Inch
Height	0.406
Number of Ribs	1
Section Size	BX
Construction Type	Cogged
Standards met	ARPM IP-20
Reinforcing cord material	Polyester
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-70 to +250 °F

General Specifications

UPC	662460346397
Weight	1.27 LB
Packaged Length	6.35 IN
Packaged Width	22.55 IN
Packaged Height	2.05 IN
HTC	4010.39.1000
Country of Origin	United States of America
