• EPDM Material provides expanded operating temperature range to -60F degrees to 250F degrees which helps ensure long-life and reliable performance in the moste demanding climates and heat sensitive applications.
• Precision Molded Cogs - Provide more surface area for heat dissipation and increase belt flexibility. Cooler running means longer life. Browning Notched belts assure longer life when replacing existing Wrapped V-Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.
• Raw-Edge Sidewalls - Improved gripping contract with pulley sidewalls. Assures less vibration and Smoother , quieter performance. Notched belts provide higher horsepower than wrapped belts.

Technical Specifications

Belt Section	BX
Type	Gripnotch Notched V-Belts
Pitch Length	145.8
Material	EPDM
Outside Length/Diameter (in)	147 in
Outside Diameter (in)	147 in
Operating Temperature [Max] ºF	250 °F
Efficiency (%)	0.98
Product Type	Notched Belt
Operating Temperature [Max] ºC	121 °C
Height	0.406
Reinforcing cord material	Polyester
Standards met	ARPM IP-20
Belt Series	Classical Series - Inch
Number of Ribs	1
Construction Type	Cogged
Section Size	BX
Width (in)	0.656 in
Operating Temperature Range	-70 to +250 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3

General Specifications

UPC	662289145393
Weight	1.22 LB
Packaged Length	16.65 IN
Packaged Width	15.80 IN
Packaged Height	2.20 IN
HTC	4010.39.1000
Country of Origin	United States of America
