• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
• Combination Groove - All Browning BK H Sheaves permit the running of A, 4L, B and 5L Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.

Technical Specifications

Pitch Diameter (A)	6.7
Material	Cast Iron
Type of Bore	Bushed
Pitch Diameter (B)	7.2
Number of Grooves	1
Datum Diameter (B)	6.9
Datum Diameter (A)	6.5
Model Name	BKH_Sheave_Master
Product Type	FHP - Bushed
Outside Diameter (in)	7.25 in
Bore (Min) (in)	0.375 in
Belt Section	4L or A, 5L or B
Outside Length (in)	1.5625 in
Bore Type	Split Taper Bushed
Bushing Bore Range	0.375 - 1.500
Overall Width (in)	1.5625
Pulley Construction	Plain
Face Width (in)	0.875

General Specifications

UPC	662289202331
Weight	3.97 LB
Packaged Length	8.50 IN
Packaged Width	8.20 IN
Packaged Height	1.20 IN
HTC	8483.50.9040
Country of Origin	Mexico
