• Largest Selection of finished bore sheaves of any other manufacturer - Browning offers finished bore sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Combination Groove - All Browning BK Sheaves permit the running of A, 4L, B and 5L Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.

Technical Specifications

Warning	Do not use these "BK" sheaves with "B" Gripnotch Belt ratings.
Material	Cast Iron
Pitch Diameter (A)	2.2
Outside Diameter (in)	2.7 in
Number of Grooves	1
Model Name	BK_Sheave_Master1
Pitch Diameter (B)	2.7
Bore (in)	0.625 in
Product Type	FHP - Finished Bore
Belt Section	4L or A, 5L or B
Bore Type	Finished with Keyway and SS
Face Width (in)	0.88
Pulley Construction	Solid
Overall Width (in)	1.32
Keyway Size	3/16 x 3/32
Number of Hubs	1
Set Screw Thread	5/16-18UNC-3AX3/8
Set Screw Tightening Torque (in-lb)	165

General Specifications

UPC	662289277674
Weight	0.91 LB
Packaged Length	3.20 IN
Packaged Width	3.30 IN
Packaged Height	1.40 IN
HTC	8483.50.9040
Country of Origin	Mexico
