• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
• Combination Groove - All Browning BK H Sheaves permit the running of A, 4L, B and 5L Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.

Technical Specifications

Type of Bore	Bushed
Pitch Diameter (A)	18.2
Model Name	BKH_Sheave_Master
Number of Grooves	1
Datum Diameter (A)	18
Datum Diameter (B)	18.4
Material	Cast Iron
Pitch Diameter (B)	18.7
Outside Diameter (in)	18.75 in
Belt Section	4L or A, 5L or B
Outside Length (in)	1.5625 in
Product Type	FHP - Bushed
Bore (Min) (in)	0.375 in
Bore Type	Split Taper Bushed
Overall Width (in)	1.5625
Pulley Construction	Plain
Face Width (in)	0.875
Bushing Bore Range	0.375 - 1.500

General Specifications

UPC	662289282494
Weight	16.11 LB
Packaged Length	19.60 IN
Packaged Width	19.40 IN
Packaged Height	1.90 IN
HTC	8483.50.9040
Country of Origin	Mexico
