• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Height	0.44
Type	Super Gripbelt V-Belts
Pitch Length	90.8
Belt Section	B
Material	Neoprene
Product Type	Wrapped Belt
Width (in)	0.69 in
Outside Length/Diameter (in)	92 in
Operating Temperature [Max] ºC	60 °C
Efficiency (%)	0.95
Operating Temperature [Max] ºF	140 °F
Outside Diameter (in)	92 in
Reinforcing cord material	Polyester
Number of Ribs	1
Construction Type	Wrapped
Section Size	B
Belt Series	Classical Series - Inch
Standards met	ARPM IP-20
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F

General Specifications

UPC	662289139385
Weight	1.13 LB
Packaged Length	5.10 IN
Packaged Width	13.85 IN
Packaged Height	2.05 IN
HTC	4010.34.3000
Country of Origin	Romania
