• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Pitch Length	79.8
Type	Super Gripbelt V-Belts
Belt Section	B
Height	0.4375
Material	Neoprene
Outside Diameter (in)	81 in
Operating Temperature [Max] ºC	60 °C
Product Type	Wrapped Belt
Width (in)	0.65625 in
Efficiency (%)	0.95
Outside Length/Diameter (in)	81 in
Operating Temperature [Max] ºF	140 °F
Belt Series	Gripbelt
Section Size	B
Band Type	Belt with Ends Joined
Standards met	MPTA IP-20;RMA
Construction Type	Classic
Reinforcing cord material	Synthetic Fiber

General Specifications

UPC	662289259250
Weight	0.97 LB
Packaged Length	5.45 IN
Packaged Width	12.15 IN
Packaged Height	2.15 IN
HTC	4010.34.3000
Country of Origin	Romania
