• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Type	Super Gripbelt V-Belts
Pitch Length	62.8
Height	0.44
Belt Section	B
Material	Neoprene
Outside Diameter (in)	64 in
Outside Length/Diameter (in)	64 in
Operating Temperature [Max] ºF	140 °F
Product Type	Wrapped Belt
Width (in)	0.69 in
Efficiency (%)	0.95
Operating Temperature [Max] ºC	60 °C
Belt Series	Classical Series - Inch
Section Size	B
Construction Type	Wrapped
Number of Ribs	1
Reinforcing cord material	Polyester
Standards met	ARPM IP-20
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3

General Specifications

UPC	662289299065
Weight	1.27 LB
Packaged Length	5.45 IN
Packaged Width	9.60 IN
Packaged Height	2.05 IN
HTC	4010.32.3000
Country of Origin	Mexico
