• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Type	Super Gripbelt V-Belts
Height	0.44
Belt Section	B
Pitch Length	44.8
Material	Neoprene
Outside Length/Diameter (in)	46 in
Product Type	Wrapped Belt
Outside Diameter (in)	46 in
Efficiency (%)	0.95
Width (in)	0.69 in
Operating Temperature [Max] ºC	60 °C
Operating Temperature [Max] ºF	140 °F
Number of Ribs	1
Standards met	ARPM IP-20
Belt Series	Classical Series - Inch
Construction Type	Wrapped
Reinforcing cord material	Polyester
Section Size	B
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3

General Specifications

UPC	662289278893
Weight	0.58 LB
Packaged Length	5.90 IN
Packaged Width	19.95 IN
Packaged Height	1.80 IN
HTC	4010.32.3000
Country of Origin	Romania
