• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Height	0.4375
Type	Super Gripbelt V-Belts
Belt Section	B
Pitch Length	43.8
Material	Neoprene
Outside Length/Diameter (in)	45 in
Operating Temperature [Max] ºF	140 °F
Efficiency (%)	0.95
Product Type	Wrapped Belt
Operating Temperature [Max] ºC	60 °C
Outside Diameter (in)	45 in
Width (in)	0.65625 in
Belt Series	Gripbelt
Band Type	Belt with Ends Joined
Reinforcing cord material	Synthetic Fiber
Construction Type	Classic
Section Size	B
Standards met	MPTA IP-20;RMA

General Specifications

UPC	662289148868
Weight	0.54 LB
Packaged Length	5.60 IN
Packaged Width	19.35 IN
Packaged Height	1.25 IN
HTC	4010.32.3000
Country of Origin	Mexico
