• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Pitch Length	315.3
Type	Super Gripbelt V-Belts
Belt Section	B
Height	0.4375
Material	Neoprene
Outside Diameter (in)	316.5 in
Product Type	Wrapped Belt
Efficiency (%)	0.95
Width (in)	0.65625 in
Outside Length/Diameter (in)	316.5 in
Operating Temperature [Max] ºC	60 °C
Operating Temperature [Max] ºF	140 °F
Belt Series	Gripbelt
Section Size	B
Construction Type	Classic

General Specifications

UPC	662289109722
Weight	3.42 LB
Packaged Length	14.70 IN
Packaged Width	16.25 IN
Packaged Height	5.30 IN
HTC	4010.39.1000
Country of Origin	Mexico
