• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Belt Section	B
Type	Super Gripbelt V-Belts
Pitch Length	27.8
Height	0.44
Material	Neoprene
Operating Temperature [Max] ºF	140 °F
Product Type	Wrapped Belt
Outside Length/Diameter (in)	29 in
Efficiency (%)	0.95
Outside Diameter (in)	29 in
Width (in)	0.69 in
Operating Temperature [Max] ºC	60 °C
Section Size	B
Construction Type	Wrapped
Belt Series	Classical Series - Inch
Standards met	ARPM IP-20
Reinforcing cord material	Polyester
Number of Ribs	1
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F

General Specifications

UPC	662289037100
Weight	0.36 LB
Packaged Length	3.75 IN
Packaged Width	12.65 IN
Packaged Height	0.80 IN
HTC	4010.32.3000
Country of Origin	Romania
