• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Pitch Length	174.8
Height	0.4375
Type	Super Gripbelt V-Belts
Belt Section	B
Material	Neoprene
Efficiency (%)	0.95
Width (in)	0.65625 in
Product Type	Wrapped Belt
Operating Temperature [Max] ºC	60 °C
Operating Temperature [Max] ºF	140 °F
Outside Length/Diameter (in)	176 in
Outside Diameter (in)	176 in
Reinforcing cord material	Synthetic Fiber
Section Size	B
Standards met	MPTA IP-20;RMA
Belt Series	Gripbelt
Construction Type	Classic
Band Type	Belt with Ends Joined

General Specifications

UPC	662289179626
Weight	1.94 LB
Packaged Length	11.00 IN
Packaged Width	26.10 IN
Packaged Height	1.70 IN
HTC	4010.39.1000
Country of Origin	Romania
