• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Pitch Length	159.8
Type	Super Gripbelt V-Belts
Height	0.4375
Belt Section	B
Material	Neoprene
Product Type	Wrapped Belt
Operating Temperature [Max] ºC	60 °C
Outside Diameter (in)	161 in
Efficiency (%)	0.95
Width (in)	0.65625 in
Operating Temperature [Max] ºF	140 °F
Outside Length/Diameter (in)	161 in
Belt Series	Gripbelt
Band Type	Belt with Ends Joined
Reinforcing cord material	Synthetic Fiber
Section Size	B
Construction Type	Classic
Standards met	MPTA IP-20;RMA

General Specifications

UPC	662289119677
Weight	1.79 LB
Packaged Length	12.20 IN
Packaged Width	24.05 IN
Packaged Height	2.15 IN
HTC	4010.39.1000
Country of Origin	Romania
