• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Height	0.4375
Pitch Length	129.8
Type	Super Gripbelt V-Belts
Belt Section	B
Material	Neoprene
Operating Temperature [Max] ºC	60 °C
Outside Diameter (in)	131 in
Outside Length/Diameter (in)	131 in
Efficiency (%)	0.95
Width (in)	0.65625 in
Operating Temperature [Max] ºF	140 °F
Product Type	Wrapped Belt
Band Type	Belt with Ends Joined
Standards met	MPTA IP-20;RMA
Construction Type	Classic
Reinforcing cord material	Synthetic Fiber
Section Size	B
Belt Series	Gripbelt

General Specifications

UPC	662289159550
Weight	1.39 LB
Packaged Length	6.40 IN
Packaged Width	19.30 IN
Packaged Height	1.95 IN
HTC	4010.39.1000
Country of Origin	Mexico
