• Wrapped construction - Provides smooth quiet operation. Single fabric design allows greater flexibility. Wrapped Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.
• High Tensile Cord - Specially treated cords to provide strength and additional flex life while providing resistance to elongation for the belt.

Technical Specifications

Belt Section	B
Type	Super Gripbelt V-Belts
Pitch Length	124.8
Height	0.44
Material	Neoprene
Outside Length/Diameter (in)	126 in
Operating Temperature [Max] ºC	60 °C
Operating Temperature [Max] ºF	140 °F
Product Type	Wrapped Belt
Outside Diameter (in)	126 in
Efficiency (%)	0.95
Width (in)	0.69 in
Section Size	B
Construction Type	Wrapped
Reinforcing cord material	Polyester
Standards met	ARPM IP-20
Number of Ribs	1
Belt Series	Classical Series - Inch
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F

General Specifications

UPC	662460345406
Weight	1.39 LB
Packaged Length	6.20 IN
Packaged Width	18.40 IN
Packaged Height	2.20 IN
HTC	4010.39.1000
Country of Origin	Mexico
